Hangcha A Series 3-Wheel Electric Lithium-Ion Forklift
Function Meets Form
The exterior of the A Series 3-Wheel Electric Hangcha Forklift is powder-coated in a durable green finish, indicating that it is powered by Hangcha’s lithium-ion technology. The robust construction of this forklift is designed to withstand the wear-and-tear of multi-shift operations enabled by lithium-ion technology. Smooth body lines meet narrow application design with the A Series.
Specs
| Model Number | Load Capacity | Width | Height | Max Fork Height | Max Full Load Lift Speed | Max Full Load Gradeability | Voltage |
|---|---|---|---|---|---|---|---|
| FBT16Li | 3,200 lbs | 43" | 81" | 156" | 74.8 fpm | 16% | 48 V |
| FBT18Li | 3,500 lbs | 43" | 81" | 156" | 74.8 fpm | 15% | 48 V |
| FBT20Li | 4,000 lbs | 43" | 81" | 156" | 74.8 fpm | 13% | 48 V |
| Model Number | Load Capacity |
|---|---|
| FBT16Li | 3,200 lbs |
| FBT18Li | 3,500 lbs |
| FBT20Li | 4,000 lbs |
| Model Number | Width |
|---|---|
| FBT16Li | 43" |
| FBT18Li | 43" |
| FBT20Li | 43" |
| Model Number | Height |
|---|---|
| FBT16Li | 81" |
| FBT18Li | 81" |
| FBT20Li | 81" |
| Model Number | Max Fork Height |
|---|---|
| FBT16Li | 156" |
| FBT18Li | 156" |
| FBT20Li | 156" |
| Model Number | Max Full Load Lift Speed |
|---|---|
| FBT16Li | 74.8 fpm |
| FBT18Li | 74.8 fpm |
| FBT20Li | 74.8 fpm |
| Model Number | Max Full Load Gradeability |
|---|---|
| FBT16Li | 16% |
| FBT18Li | 15% |
| FBT20Li | 13% |
| Model Number | Voltage |
|---|---|
| FBT16Li | 48 V |
| FBT18Li | 48 V |
| FBT20Li | 48 V |
*Based on 24″ load center
**Add load length and clearance. Product specifications may not reflect the most current product details. Authorized Hangcha dealers retain the most current product specifications. All specifications should be verified by an authorized Hangcha dealer prior to purchase.
Overview
The Hangcha A Series 3-wheel Electric forklift with a Lithium-Ion battery is highly maneuverable, efficient, and durable, designed for tight spaces and multi-shift operations. The 3-wheel design, combined with independent front-wheel drive and a rear steering wheel, enables a tight turning radius and 360° turning within its footprint. Features like automatic speed control during turns and an electronic parking brake enhance operator and load safety.
Performance
- CATL lithium-ion battery pack
- Dual front AC-driving motors
- Solid pneumatic tires
- 2 hydraulic valves inside the chassis
- Electronically-controlled travelling, lifting, and steering
- CAN bus system
- Low noise gear pump
- Full hydraulic steering
- Non-suspension Grammer GS12 seat with switch
Ergonomics
- Multi-function instrument display
- Rubber floor mat
- 189″ triple wide view mast
- Adjustable steering column
Safety Features
- Meets ANSI and ITSDF safety standards
- Overloading protection system
- Controller automatically reduces the forklift’s speed while cornering
- Emergency disconnect switch
- LED headlights
- Rear combination LED light
- Panoramic rearview mirror
- Horn and backup alarm
Ease of Service
- Tool-less floorboard removal
- Integrated Battery Management System (BMS) continually monitors energy management
Options
