JLG IC 600AJ Series Aerial Lift
The 600AJ Series boom lift features a narrow chassis option for access to confined areas and an industry-leading work envelope. A standard oscillating axle and optional four-wheel drive deliver outstanding off-road performance. Jib-equipped models add 70° of upward and 60° of downward motion to get you into those hard-to-reach places. The Hi-Capacity (HC) model lets you push the envelope without compromise, with three capacity zones, each rated for three occupants and tools.
Specs
| Model Number | Platform Capacity | Machine Width | Machine Length | Machine Height | Working Height | Horizontal Outreach | Drive Speed |
|---|---|---|---|---|---|---|---|
| 600AJ HC3 | 1000 lbs | 8' 2" | 30' | 8' 6" | 60' | 40' 7" | 4WD 4.3 mph |
| 600AJ | 500 lbs | 8' 2" | 29' | 8' 4" | 60' 7" | 39' 9" | 4WD 4.3 mph |
| 600AJN Narrow | 500 lbs | 7' | 29' | 8' 4" | 60' 7" | 39' 9" | 4WD 4.3 mph |
| Model Number | Platform Capacity |
|---|---|
| 600AJ HC3 | 1000 lbs |
| 600AJ | 500 lbs |
| 600AJN Narrow | 500 lbs |
| Model Number | Machine Width |
|---|---|
| 600AJ HC3 | 8' 2" |
| 600AJ | 8' 2" |
| 600AJN Narrow | 7' |
| Model Number | Machine Length |
|---|---|
| 600AJ HC3 | 30' |
| 600AJ | 29' |
| 600AJN Narrow | 29' |
| Model Number | Machine Height |
|---|---|
| 600AJ HC3 | 8' 6" |
| 600AJ | 8' 4" |
| 600AJN Narrow | 8' 4" |
| Model Number | Working Height |
|---|---|
| 600AJ HC3 | 60' |
| 600AJ | 60' 7" |
| 600AJN Narrow | 60' 7" |
| Model Number | Horizontal Outreach |
|---|---|
| 600AJ HC3 | 40' 7" |
| 600AJ | 39' 9" |
| 600AJN Narrow | 39' 9" |
| Model Number | Drive Speed |
|---|---|
| 600AJ HC3 | 4WD 4.3 mph |
| 600AJ | 4WD 4.3 mph |
| 600AJN Narrow | 4WD 4.3 mph |
Product specifications may not reflect the most current product details. Authorized JLG dealers retain the most current product specifications. All specifications should be verified by an authorized JLG dealer prior to purchase.
Overview
The JLG IC 600AJ Series offers a diesel or dual fuel articulating boom lift, renowned for its maneuverability and superior reach envelope. It is an ideal lift for navigating confined job sites with obstacles and is well-suited for applications such as general construction, maintenance, and electrical work.
Performance
- Best reach envelope in its class
- Optional articulating jib gets you into hard-to-reach places
- Unmatched maneuverability for confined work areas
- Fuel-efficient Tier 4 engine
- Range of articulation 130°
- Up and over height of 26’7″
Ergonomics
- Customer-preferred proportional controls
- Platform console status light panel
- Spacious platform
- 180° hydraulic platform rotator
- 110 V AC receptacle
Safety Features
- Platform guard rails
- Self-closing gate
- Tilt alarm
- Tilt indicator light
- Oscillating axle
- Automatic load-sensing system
- Machine status light panel
- All-motion alarm
- LED motion/amber beacon
- Crushing hazard decals
- Emergency stop button
- Emergency lowering system
Ease of Service
- Swing-out engine tray
- Zero-calibration automatic load-sensing system
- Enhanced light panel with status indicators
- 12 V DC auxiliary power outlet
